Italy Micro Detectors Sensor DM3/0N-1A In Stock

DM3/0N-1A MICRO DETECTORS Photoelectric sensor 100 mm diffuse NPN with adjustment, cable 2m axial

Description:
Photoelectric sensor 100 mm diffuse NPN with adjustment, cable 2m axial
DM3/0N-1A Photoelectric sensor 100 mm diffuse NPN with adj. cable 2m axial

Nominal sensing distance：100mm
Thermal drift of Sr：≤10% Sr
Repeat Accuracy：5%
Sensitivity adjustment：Yes
Output type：NPN
Output Function：LO/DO selectable
Switching frequency：400Hz
Operating Voltage：10…30Vdc
No-Load supply current：≤30mA
Load current：≤100mA
Leakage current：≤10μA
Output voltage drop：≤2V IL =100 mA
Max ripple content：≤ 10%
LED indicators：Yellow
Time delay before availability：≤150ms
Short-circuit protection：Yes
Reverse Polarity Protection：Yes
Emission：Infrared (880nm)
Interference to external light：3.000lux (incandescent lamp), 10.000lux (sunlight)
Impulsive Overvoltage Protection：Yes
Dimensions：M12x1/L=54,5mm
Weight：60g
Operating temperature：- 25°C…+ 70° C
